Commercial Wall-Mounted Extractor Hood - 1400mm - with Baffle Filters & Lighting
Installation depth: 1400 mm
SKU KLP1414
* The picture may slightly differ from the original.
Print* net price | gross price incl. 19% VAT.: €796.10
Commercial Wall-Mounted Extractor Hood - 1400mm - with Baffle Filters & Lighting
SKU KLP1414
Installation depth: 1400 mm
Print* net price | gross price incl. 19% VAT.: €796.10
Spare Parts (2)
Product Advantages
- Made in Europe: Represents high quality standards and sustainable production.
- High-quality workmanship: Ensures durability and reliability in use.
- Single-block structure made of AISI 304 stainless steel: Provides robustness and easy cleaning.
- Grease-free labyrinth filters made of 18/10 stainless steel: Guarantee effective grease separation and hygiene.
Description
Product Overview
The canopy hood with a width of 1400mm is ideal for professional use in kitchens and catering establishments. It impresses with its compact and robust design, which guarantees long-lasting use. Thanks to the integrated lighting, it provides optimal visibility when cooking and working. The hood is perfectly suited to efficiently extract vapours and fats, thereby creating a clean indoor climate.Product Details
Made from high-quality AISI 304 stainless steel, the hood offers a durable and hygienic surface that is easy to clean. The electronically welded construction ensures high stability and quality. Particularly practical is the drip-free, hermetic gutter with drain taps, which facilitates the collection and emptying of grease, thus simplifying maintenance work. The grease-free labyrinth filters made of 18/10 stainless steel guarantee effective air filtration, while the satin-finished surface in Scotch-Brite look provides an attractive appearance. Installation is completed within minutes, making on-site use especially straightforward.Conclusion and Areas of Application
This canopy hood is the optimal solution for those who value efficient grease separation and easy cleaning. It is excellently suited for use in restaurants, canteens, large-scale kitchens, and other commercial kitchens. Thanks to its well-thought-out design and high-quality materials, it supports a hygienic and safe working environment. With this hood, air quality is improved and kitchen work is significantly eased.Installation & Operation
- ⚠️ Pipe diameters should always remain consistent or only be reduced following professional planning.
- ⚠️ An incorrect reduction can affect the entire system.
Cleaning & Maintenance
Cleaning & Maintenance AI Input
- Modern flame-retardant filters made of stainless steel are designed to be cleaned in commercial dishwashers.
- Daily cleaning prevents burning-in/resin build-up.
- Carefully lift the filter out of the holder (caution: fat droplets!).
- For heavy soiling, rinse coarse grease off with hot water.
- Wash in the dishwasher at high temperatures (at least 60–70 °C) using a degreasing detergent.
- The filters must be completely dry before being reinserted to prevent mould or bacterial growth.
Technical data
Dimensions
| Width | 1.400 mm |
|---|---|
| Depth | 1.400 mm |
| Height | 450 mm |
Filter dimensions
| Width | 400 mm |
|---|---|
| Depth | 500 mm |
Details
| Number of filters | 3 |
|---|---|
| Conveyor volume | 1.800 m³/h/h |
Connected load
| Voltage | 230V |
|---|---|
| Phase(s) | 1N/PE |
| Frequency | 50 Hz |
Delivery
| Shipping method | Haulage |
|---|---|
| Delivered as | Mounted |
| Gross weight | 52 kg |
| Net weight | 46,80 kg |
Download / Exploded drawing
Download / Exploded drawing
Safety and disposal instructions
Safety and disposal instructions
Download / Exploded drawing
Safety and disposal instructions
