* The picture may slightly differ from the original.
Split freezer refrigeration unit - for up to 3 m³
Rate now
SKU TSC100
Temperature: -15 to -15 °C
Print* net price | gross price incl. 20% VAT.: £2,567.83
Accessories
Description
Design
- Protection class IP 23
- With lighting
- Condensation water drain
- Condensation drainage connection
- Electronic control
- To the outside
- With heating
- Connection for pre-filled coolant lines
- Door contact switch - high pressure switch and remote control panel
- Self-supporting housing (galvanised powder-coated sheet)
- Hermetic compressor with thermal winding protection
- Heat exchanger with copper tubes and aluminum fins
- Particularly hygienic due to easy cleaning
Quality
- Long service life
- High quality split unit
- High precision and stability
- Compact chiller unit as split device
- Superior product made in Europe
Insulation
- Corresponding to the EU guidelines (Halon regulations)
- Particularly energy-efficient due to the insulation at the top
- Top-quality insulation values through the use of polyurethane
Cooling
- With refrigerant
- Temperature: -25 °C to -15 °C
- Maximum room volume: 3 m³
- Refrigerant: R452a / 0,90 kg
- Air cooled condensers
- Ambient air temperatures up to +43 °C
- Powerful and constant cooling
- Automatic defrosting can be programmed by a regulator
Connection
- Compressor output: 602 Watt
- Electrical connection: 230V / 50 Hz
- Supplied with CEE plug
Dimensions
- External dimensions of unit W x D x H: 400 mm x 320 mm x 720 mm
- External dimensions evaporator W x D x H: 656 mm x 433 mm x 188 mm
Scope of delivery
- Including contact switch
- Includes the interior lighting for the cooling room
- Refrigeration unit and vaporiser
- 5 m Pipeline
- Refrigerant
- Supplied without refrigeration cell
Notes
- The refrigeration cell must be ordered separately
- Winter equipment for outdoor use available subject to a surcharge
Guidelines
- Manufactured in accordance with relevant hygiene and safety standards
- Manufactured in accordance with relevant hygiene and safety standards
- Material complies with European food standards
OPTIONAL ACCESSORIES:
- TC series refrigeration cell
Technical data
Dimensions
| Width | 400 mm |
|---|---|
| Depth | 320 mm |
| Height | 720 mm |
Liquefier
| Fan Ø | 254 mm |
|---|---|
| Air volume | 650 m³/h |
Evaporator
| Fan Ø | 200 mm |
|---|---|
| Air volume | 630 l/h |
| Air dispersion | 3 m |
| Expansion | expansion valve |
About recommended room volume
| D + S cables Ø | 6/10 |
|---|---|
| At +32 °C outside temperature | 3.0 m³ |
| At +43 °C outside temperature | 1.7 m³ |
Details
| Drawing no. | Aa |
|---|---|
| Refrigerant | R452a / 0,90 kg |
| Compressor output | 602 Watt |
| Temperature | -25 °C to -15 °C |
| Connection values | 230 V / 1PH - 50 Hz |
| Power consumption | 3,4 A |
Delivery
| Shipping method | Parcel |
|---|---|
| Delivered as | Mounted |
| Weight | 58 kg |
