Compact Glasswasher - Touchscreen - 3.3kW - with Drain Pump, Detergent & Rinse Aid Pumps

* The picture may slightly differ from the original.
Compact Glasswasher - Touchscreen - 3.3kW - with Drain Pump, Detergent & Rinse Aid Pumps
Product Advantages
- Intuitive touchscreen operation: Allows simple and fast control of the machine, significantly enhancing user comfort.
- Remaining time display: Provides information on the remaining wash cycle time, enabling better scheduling of processes.
- Varied adjustment options: Offer flexibility in use and allow individual customisation to different needs.
- Automatic detergent & rinse aid supply: Ensures optimal dosing and saves time and effort during operation.
Description
Overview of the Dishwasher
The dishwasher with touch control offers a powerful solution for the professional cleaning of crockery in the gastronomy and large-scale kitchen sectors. With a rated power of 3.30 kW, it guarantees a fast and thorough washing performance. The appliance is designed as an under-counter unit, thus fitting space-savingly into any kitchen run.
Product Details and Technical Features
The machine is equipped with a detergent, rinse aid, and alkali pump, ensuring effective dosing and discharge of cleaning liquids. The wash arm made of polypropylene is particularly durable and guarantees long-lasting functionality. The door opening with safety system ensures safe operation and prevents unintended opening during the wash cycle.
Adjustable feet allow for optimal height adjustment for various installation locations. The wash programmes are digitally controlled and enable precise temperature regulation for washing and rinsing processes, resulting in efficient cleaning. The housing, made of high-quality stainless steel, is fully sealed to IPX5, thus protecting against water damage.
The rotating, non-clogging wash and rinse arms ensure an even distribution of water, while the alkali pump reliably discharges wastewater even over height differences. The electric detergent supply is designed according to international safety standards.
Conclusion and Areas of Application
This dishwasher is ideal for professional use in gastronomy, large kitchens, and catering operations. It impresses with its easy touch operation, high washing performance, and durable construction. Thanks to the robust components and well-thought-out technology, it is perfectly suited for daily, intensive use. Its versatile programmes and safety features make it a reliable and efficient solution for clean crockery in large quantities.
Installation & Operation
- ⚠️ Information about the mains voltage can be found in the operating manual.
- ⚠️ To reduce the heating time, a hot water connection should be used.
- ⚠️ The maximum temperature of 50°C must not be exceeded.
- ⚠️ A detailed guide can be found under the "Download" and "Video" tabs.
Cleaning & Maintenance
- For flawless operation, it is recommended to descale the device regularly – suitable descalers are available as accessories.
- If a descaler is installed upstream, please note that the cartridge must be regenerated after approximately 1500 - 2000 litres of water flow.
- The actual maximum flow rate depends on the water hardness.
- Use only chlorine-free cleaners to protect the device.
Technical data
Dimensions
| Width | 475 mm |
|---|---|
| Depth | 540 mm |
| Height | 765 mm |
Basket dimensions
| Width | 400 mm |
|---|---|
| Depth | 400 mm |
Rack height
| Height | 330 mm |
|---|
Water connection
| Water inlet | R 3/4" |
|---|---|
| Water drain | R 3/4 |
Details
| Operation | Touchscreen |
|---|---|
| Washing pump power | 270 Watt |
| Maximum volume | 70 dB |
| Max. Crockery height | 320 mm |
Flushing process
| Washing temperature | 55 - 60 °C |
|---|---|
| Purge temperature | 80 °C - 85 °C |
| Washing program 1 | Washing time 105 seconds, 33 baskets / hour |
| Washing program 2 | Washing time 135 seconds, 26 baskets / hour |
| Rinse program 3 | Rinse time 195 seconds, 18 baskets / hour |
| Water consumption per run | 2,50 l |
Capacity
| Tank capacity | 18,40 l |
|---|---|
| Boiler capacity | 2,80 l |
Connected load
| Power | 3,30 kW |
|---|---|
| Voltage | 230V |
| Phase(s) | 1N/PE |
| Frequency | 50 Hz |
Delivery
| Shipping method | Haulage |
|---|---|
| Delivered as | Mounted |
| Gross weight | 43 kg |
| Net weight | 35 kg |
Download / Exploded drawing
